Product overview
The NSX-5000V is a trace element analyzer built for demanding trace elemental analysis of nitrogen, sulfur, and chlorine in liquid and gas samples.
The NSX-5000V series is a trace elemental analysis system that meets the demands of environmental responsibility without sacrificing analytical performance. As a trusted trace element analyzer supplier, we offer services across UAE, Saudi Arabia, Qatar, Kuwait, Oman, and Bahrain, for automatic measurement of trace amounts of nitrogen, sulfur and chlorine in liquid and gas samples with high sensitivity and reliable safety features .
Such a trace elemental analyzer can be used for a variety of applications including quality control of petroleum, chemical and recycled products, automotive fuel testing and environmental sample analysis. Designed for demanding, reproducible trace elemental analysis with minimal manual intervention, the NSX-5000V vertical furnace system is ideal if you work in a QC lab or environmental testing facility.
| ASTM D5453, D7183, D6667, D7551, D4629, D5808, ISO 20846, IP/EPA Methods |
| ASTM D5453, D4929, D7183, ISO 20846, JIS Methods |
| ASTM D5987, D7359, DIN/ISO Combustion Methods |
Automatic syringe dilutor (ASC-550L)
The accuracy of dilution should be independent of the operator. The ASC-550L requires only the addition of stock solution and solvent into vials, and the system performs the dilution automatically. There is no need to prepare calibration curves beforehand and less solvent waste means less impact on the environment and lower operating costs.
User-friendly software
It comes with Simple and Advanced modes, which makes it ideal for routine lab testing, as well as more detailed product quality control work.
Low operating costs
The NSX-5000V also uses less gas than previous models and has the ability to shut off the flow of gas once a measurement is complete, helping labs manage their operating costs over time.
Simple daily care
The furnace can be opened/closed to visually check the pyrolysis tube and do routine maintenance without long downtimes.
Audit trail
All activity performed on the instrument is logged for audit readiness. If you need the history, it is always there in Advanced mode.
Managing users
To protect analytical methods and stored data from accidental modification or deletion, labs conducting regulated testing must have three levels of login access.
Wide range, user friendly
The sensitivity settings for each of the detectors can be switched from high to low ranges by simple selection. This allows the system to be accessible to a variety of sample types and concentrations.
Reanalysis capability
If necessary the start and end times of the chart data can be changed after measurement so that results can be optimised without the need to repeat the entire test run.
| Sulfur | Nitrogen (aqueous) | Nitrogen
(non-aqueous) |
Chlorine | Sulfur | |
| Detector | SD-500 | ND-500 | MCD-500 | ||
| Sample | Liquid / Gas | ||||
| Analytical method | UV fluorescence | Chemiluminescence | Micro coulometry | ||
| Furnace | Max. 1,100℃, Openable electric furnace, 2-section type | ||||
| Measuring range | 2 to 20,000µg
(up to 10,000 µg/mL) |
3 to 20,000µg
(up to 10,000 µg/mL) |
1 to 10,000µg
(up to 5,000 µg/mL) |
10 to 500,000µg
(up to 5,000 µg/mL) |
20 to 50,000µg
(up to 1,000 µg/mL) |
| LOQ | 0.02µg/mL | 0.03µg/mL | 0.01µg/mL | 0.05µg/mL | 0.1µg/mL |
| Sample volume | Liquid: Max 200µL | Liquid: Max 100µL | Liquid: Max 200µL | ||
| Measurement time | Less than 3 min | Less than 10 min | |||
| Gas used | Argon: Purity 99.98% or more, 0.3±0.1 MPa, Oxygen: Purity 99.7% or more, 0.3±0.1 MPa | ||||
| Power supply | VF-500: AC100 / 115V (50 / 60 Hz), 1,100 VA AC230/ 240 V, (50/ 60 Hz), 1,800 VA
SD/ ND/ MCD-500: AC100 – 240 V, 300 VA |
||||
| Mass and weight | VF-500: 500 (W)×430 (D)×500 (H) mm, approx. 35 kg, SD-500: ND-500: 220 (W)×375 (D)×500 (H) mm, approx. 21 kg,
ND-500: 220 (W)×375 (D)×500 (H) mm, approx. 22 kg, MCD-500: 220 (W)×375 (D)×500 (H) mm, approx. 14 kg, |
||||
The NSX-5000V trace element analyzer is used in many industries where accurate nitrogen, sulfur and chlorine analyzers are critical to quality and compliance Petroleum refineries, Special fuels, Pipeline and terminal operations, Testing of military fuels and Jet fuel testing.
These applications are a perfect illustration of the instrument’s key strength, in terms of consistent, standards-compliant trace element testing across a wide range of sample types from raw feedstocks to finished fuel products.
